ESAB, 245015904, Flux-Cored Welding Wire, 1/16 in; 210-545 A, Mild Steel, E71T-1M/T-9M

Dual Shield 70 Ultra Plus is an all-position wire that is uniquely designed to provide high deposition, outstanding all position performance and a fume emission rate approaching that of solid wires. It is optimized for use with 90% Ar/10% CO2 shielding but works well with mixes ranging from 75% Ar/25% CO2 to 95% Ar/5% CO2. Among the outstanding features of Dual Shield 70 Ultra Plus are a very wide operating window, very high out of position deposition rates (vertical up and overhead at over 12 lb/hr), and welds that are virtually spatter free. Dual Shield 70 Ultra Plus may be used in a variety of applications including railcar, automotive, heavy equipment, and general structural steel fabrication. It is especially recommended in applications where reduction of welding fume is a priority.

Applications

• Railcars
• Steel Industry
• Industrial and General Fabrication
• Process
• Civil Construction
• Ship/Barge Building
• Bridge Construction
• Mobile Equipment
• Automotive

Prop 65

• Yes

• Amperage Range: 210 Amps - 545 Amps
• Wire Diameter: 1/16 in.
• Material: Mild Steel
• Welding Process: Flux-cored (FCAW)
• Tensile Strength: 86 ksi
• Shielding Gas: 75-95% Ar / 5-25% CO2 (optimal 90% Ar / 10% CO2)
• AWS Classification: E71T-1M/T-9M
• Trade Name: DUAL SHIELD
• Carcinogen: Lead
• Reproductive: Dual Short Form
• Country of Origin: United States
