ESAB, 243410206, Metal Core Welding Wire, 0.035 in, 80-85 ksi, E70C-6M-H4, 130-260 Amps, Wire Spool

Coreweld 70 is a tubular wire containing ingredients primarily comprised of metal powder along with additional arc stabilizers and alloying elements. The net result is a high efficiency (90 to 98%) wire. Arc characteristics, weld metal transfer, spatter levels are improved, while silica islands are minimized with the use of Argon mixtures up to 92% Argon. Due to the high level of iron powder and low slag components, the only slag formed by this wire are small islands of silica. Coreweld 70 was designed for multipass welding in robotic applications where slag removal between passes is difficult. This metal cored product is intended for use on carbon steels having tensile strengths up to 70 ksi (485 MPa). Coreweld 70 wires from .045" up to 1/16" are capable of being welded out-of-position.

Prop 65

• Yes

Applications

• Mobile Equipment
• Industrial and General Fabrication
• Automotive
• Civil Construction
• Railcars
• Power Generation
• Bridge Construction
• Pipeline
• Ship/Barge Building

• Tensile Strength: 80-85 ksi
• Amperage Range: 130 Amps-260 Amps
• Diameter: 0.035 in.
• Material: Mild Steel
• AWS Classification: E70C-6M-H4
• Process: MCAW
• Country of Origin: United States
• Wire Type: Metal Core
• Weld Position Capability: Out-of-position (for 0.045 to 1/16 in.)
