Harris Products Group, 00D0C38, MIG Welding Alloy, Deoxidized Copper, Corrosion Resistant, Conforms to ANSI/AWS A 5.7

Deoxidized Copper MIG (GMAW) welding alloy is used to weld high copper content base metals where good electrical conductivity exists. This alloy produces trouble free welds that are a good color match to copper. Deox copper can also be used to weld copper-to-steel. Conforms to ANSI/AWS A 5.7 & ASME SFA-5.7 ERCu.

Features

• Designed to weld high copper content base metals with good electrical conductivity
• Yields trouble-free welds
• Produces high purity deposits for fabricating deoxidized copper
• Excellent corrosion resistance
• Reddish brown color is a good match to copper
• Typical applications include welding copper-to-steel or to overlay it
• Conforms to ANSI/AWS A 5.7 & ASME SFA-5.7 ERCu
• Pre-heat required due to high thermal conductivity of copper base materials. Must select the current and shielding gas for the highest heat input
• Use with 100% Argon or 25/75% Argon/Helium shielding gas mixture

• Recommended Amperage Range: 130-280 A (GMAW)
• Recommended Voltage Range: 21-30 V (GMAW)
• Weight: 1.14 lbs
• Recommended Wire Diameters: .030 in, .035 in, .045 in, 1/16 in
• Material: Deoxidized Copper
• Electrical Conductivity: 40% IACS
• Melting Point: 1967 F (1075 C)
• Yield Strength: 8,000 psi
• Tensile Strength: 29,000 psi
• Elongation: 29%
• Brinell Hardness: 54 HB (500 kg load)
• Reduction of Area: 45%
• Recommended Wire Feed Speed: 150-500 ipm (GMAW)
• Recommended Argon Flow: 25-40 cfh (GMAW)
• Recommended Shielding Gas: 100% Argon or 25/75% Argon/Helium mixture
• Compliance: ANSI/AWS A 5.7, ASME SFA-5.7 ERCu
• Welding Method: GMAW (MIG)
