Thermal Dynamics, 1-1334-2, Plasma Cutter, 460 V, SL100 Torch, 25 ft Cable, 100% Duty Cycle, 1" Maximum Cutting Capacity

The Thermal Dynamics Cutmaster A80 Plasma Cutter with Machine Torch (1-1334-1) sets the standard in FlexThermibility, value and performance and ushers in the next generation of automated Cutmaster systems. Light-weight, compact design and convenient mounting feet allow for easy mounting in any application while its powerful 80% duty cycle handles all-day production cutting in the toughest environments. The new A-Series includes the SL100 SV 1Torch with standard 25 ft. ATC Quick Disconnect. Their 1Torch start technology eliminates the electronic interference that can occur with other designs. 1Torch provides quick, reliable starts and a strong pilot arc to pierce heavy plate. With auto-pilot restart, it can also cut expanded metal quickly and easily. With all the advantages of 1Torch and proven Cutmaster reliability, the new automated Cutmaster A-Series delivers the best in productivity, precision and performance.

Accessories

• 50'/15.2m CNC Cable for Automation Interface Kit 9-1011
• Nylon Dust Cover 9-7071
• Automation Interface Kit for Start/Stop, OK to move and Divided Arc Voltage) 9-8311
• Replacement Filter Hose 9-7742
• Two - Stage Air Filter Assembly 9-7527
• Second Stage Cartridge 9-1022
• Single-Stage Filter Kit (includes Filter & Hose) 7-7507
• Multi - Purpose Cart 7-8888
• Replacement Filter Element 9-7741
• Extended Work Cable (50 ft / 15.2 m) with Clamp 9-8529
• 35'/10.7m CNC Cable for Automation Interface Kit 9-1010
• Automation Harness for Start/Stop and OK to move 9-9385
• Replacement Filter Body 9-7740
• Two -Stage Filter Kit (includes Hose & Mounting Screws) 9-9387
• 25'/7.6m CNC Cable for Automation Interface Kit 9-1008
• First Stage Cartridge 9-1021

Applications

• Industrial

Features

• Light-weight, compact design and convenient mounting feet allow for easy mounting in any application
• Dedicated automation software improves cycle time and performance in many applications
• Software automatically detects the torch that is attached and switches between automation and manual modes
• Full arc voltage is available using an internal terminal connection
• A powerful 80% Duty Cycle to handle all-day production cutting in the toughest environments
• Valve in torch design reduces cycle time between parts and increases productivity
• CNC Interface connection is located on the rear of the power supply offering “Start/Stop”, “OK to MOVE” and divided arc voltage

• Voltage: 460 V
• Output DC Amps (Max): 30 - 80 Amps, 100 Amps Max.
• Duty Cycle: 100% @ 70 Amps
• Maximum Cutting Capacity: 1 in.
• Maximum Severance: 1 in.
• Maximum Pierce: 3-4 in.
• Recommended Cutting Capacity: 3/4 in.
• Cable Length: 25 ft
• Physical Size (Inches): 33.5 x 15.25 x 23.5
• Phase: 1 or 3
• Torch Model: SL100
• Trade Name: Cutmaster A80
• Country of Origin: Mexico
