Victor, 0781-5230, Two Stage Regulator, Acetylene, 9/16" - 18 UNF (LH), CGA-510, 2 - 15 psig

Victor® ETS4 EDGE™ Series Two Stage High Capacity Acetylene Regulator offers 2 - 15 psig delivery range and is used for applications where precise and constant outlet pressure is required. Regulator with maximum inlet pressure of 3000 psig provides reliable performance. It features forged brass body, zinc-aluminum housing caps, high impact ABS gauge guard and 2.7" fabric reinforced neoprene diaphragm. It has 400 inlet gauge range and 30 outlet gauge range. Regulator has a compact layout with built in gauges that are recessed into the body for protection. Regulator with 510 CGA inlet connection features 9/16"-18 LH(M) outlet connection. It features advanced design which is a blend of form and functionality. Regulator with easy to read gauges having enhanced graphics has color-coded knobs to allow quick gas identification. User friendly architecture features side mounted knob that provides natural as well as safe hand/body positioning to adjust delivery pressure. It has a single impact point configured to assist in safeguarding elements critical to system integrity. Regulator provides uniform flow performance over various range of cylinder pressures with high sensitivity and accuracy in delivery pressure. Regulator includes external self-reseating relief valve, stem type seat mechanism and nickel plated bronze sintered inlet filter. It comes with color-coded SLAM™ impact absorbing safety knob for added strength, safety as well as protection of the regulator internals. Regulator has five-year warranty and meets or exceeds CGA E-4, UL 252 and ASTM G-175 promoted ignition test.

Features

• Brass adjusting screw with forged T-Handle
• Stem type seat mechanism
• Adjusting spring pretested for quality assurance
• Stainless ball in key for easy adjustment
• Stainless steel diaphragm gives accurate long lasting service
• Precision machined nozzle for optimum flow control
• Regulators will deliver at least the stated upper range and in some cases may exceed the stated upper range
• Sintered inlet filter electroless nickel plated bronze
• Conforms to CGA E-4
• Delrin insert bushing for durability, easier adjusting
• Die forged brass spring housing cap provides greater strength and durability
• UL 252 Listed

Applications

• Structural Steel Fabrication
• Light Fabrication
• Repair And Maintenance
• Industrial And General Fabrication

• Fuel Gas: Acetylene | C2H2
• Delivery Rate: 2 - 15 psig
• Maximum Inlet Pressure: 3000 psig
• Outlet Connection: 9/16 in - 18 UNF (LH)
• Inlet Connection: CGA-510
• Regulator Type: Two Stage Regulator
• Gauge Diameter: 1.5 in
• Physical Size: 8.5 x 8 x 8.8 in
• Workload: High Capacity
• Body Material: Brass
• Housing Cap Material: Zinc-Aluminum
• Gauge Guard Material: ABS
• Diaphragm Material: Neoprene
• Diaphragm Thickness: 2.7 in
• Inlet Gauge Range: 400 psig
• Outlet Gauge Range: 30 psig
• Inlet Filter Material: Nickel-Plated Bronze
• Compliance: UL 252 Listed, CGA E-4, ASTM G-175
• Country of Origin: Mexico
• Model: ETS4-15-510
• Trade Name: EDGETM
