ESAB, 0558102556, Multi-Process Welder, 300 A, 460-575 V, MIG, TIG, Stick, 10 ft Lead Cord, 3 Phase

The ESAB® Rebel™ EMP 285ic Industrial, multi-process packages. Introducing Rebel™ EMP 285ic 3ph systems, the most powerful, industrial Rebel yet for excellent performance on MIG, Flux-Cored, TIG and Stick applications. Capable of welding up to 350A, this TRUE multi-process, multi-voltage industrial welding machine runs the full range of .035 in. (0.9 mm) and .045 in. (1.2 mm) wires. It's the most portable, mobile welder in its class and has the power and performance to crush even the most demanding industrial jobs.

Features

• CSA
• Power to Perform - with 285A @ 50% (3ph model) you'll have the confidence to run the full range of .045 in. (1.2 mm) wire, short arc and spray transfer, with increased deposition rates and higher productivity on smaller diameter wires such as .030 in. (0.8 mm) and .035 in. (0.9 mm)
• Detach the Rebel EMP 285ic from its cart and tackle any job around the shop or out at the job site
• sMIG Technology - innovative "smart-MIG" feature that dynamically monitors the arc characteristics ultimately adapting to your technique resulting in a smooth, stable arc
• Set wire diameter and plate thickness and you are ready to weld
• With ESAB's new 4 Roll Drive System, weld up to .052 in. (1.4 mm) solid wire and up to 1/16 in. (1.6 mm) cored wire
• Unmatched Portability/Mobility - weighing in at 70 lbs. (32 kg) with multi-voltage, multi-phase capability and 4 handle roll cage
• 3 Year Warranty
• TFT Multilingual Display - packed full of features, Rebel EMP 285ic has 4 programmable memory locations for each process, multi-language selection, trim adjustment, inductance control, pre/post flow control and spot weld setting giving you the ability to fine tune your welds for the most optimal performance
• 100% Satisfaction Guarantee
• Electrodes up to 5/32 in. (4.0 mm) and TIG rods up to 3/16 in. (5.0 mm)

Applications

• Training Schools
• Maintenance And Repair
• Industrial Production And Manufacturing
• Industrial And General Fabrication
• Civil Construction
• Mechanical Contractors
• Agricultural Equipment

Accessories

• Tweco Ground Clamp w/Lead, 10 ft. (3 m), 50 mm Dinse WS200G10
• Spray Master Velocity 350V MIG Gun, 15 ft. (4.5 m) 1036-1756
• Spray Master Velocity 250V MIG Gun, 15 ft. (4.5 m) 1023-1277
• Electrode Holder 200A and Lead Assembly, 13 ft. (4 m), 50 mm WS200E13
• Victor HRF 1425-580 Regulator/Flowmeter 0781-2743
• Rebel Single Cylinder Cart 0558102491
• Power Adapter - 230V to 120V, 15A W4014000
• Foot Control, 15 ft. (4.6 m) cable and 8-pin Male Plug W4014450
• ESAB TXH 201 5/8 npt 12.5 ft. (3.8 m) TIG Torch Outfit 0558102493
• Tweco 200A Spool Gun, 12 ft. (3.6 m) 1027-1398

Prop 65

• Yes

• Voltage: 460 V, 575 V
• Phase: Three Phase
• Maximum Output Current: 300 A
• Duty Cycle: MIG: 285 A @ 50%
• Current Range: 5 - 300 A
• Wire Diameter Range: 0.023 - 1/16 in.
• Wire Feed Speed Range: 60 - 800 ipm
• Maximum Plate Thickness: 1/2 in.
• Output Mode: CC/CV
• Process: MIG (GMAW), DC TIG (GTAW), Flux Cored (FCAW), STICK (SMAW)
• Physical Size (L x W x H): 26.5 x 11.5 x 19.5 in.
• Weight: 70 lbs (32 kg)
• Wire Spool Sizes: 4 in, 8 in, 12 in
• Wire Size: 0.023" - 1/16"
• HZ: 50/60 Hz
• Protection Class: IP23S
• Compliance: CSA, UL, IEC
• Nominal OCV Voltage: 68 VDC
• Supply Voltage Range: 90 - 270 VAC
• Electrode Size: up to 5/32 in (4.0 mm)
• TIG Rod Size: up to 3/16 in (5.0 mm)
• Country of Origin: China
