ER410 stainless steel welding wire is used to weld straight chromium steels such as AISI types 403, 405, 410, 414 and 416. It is also used as an overlay on carbon steels to give added resistance against corrosion and abrasion. Preheat and post-heat treatment is required.

  • Weight: 33 lb
  • Wire Diameter: 0.045 in.
  • Alloy Type: ER415
  • Material: Stainless Steel
  • Applicable Steel Types: AISI 403, 405, 410, 414, 416
  • Preheat Temperature Range: 350-500 F
  • Postheat Temperature Range: 1350-1400 F
  • Postheat Duration: 1 hour per inch
  • Typical Composition - Carbon: 0.08%
  • Typical Composition - Manganese: 0.50%
  • Typical Composition - Silicon: 0.40%
  • Typical Composition - Molybdenum: 0.15%
  • Typical Composition - Sulfur: 0.03%
  • Typical Composition - Chromium: 12.90%
  • Typical Composition - Nickel: 0.40%
  • Tensile Strength: 80,000 psi
  • Yield Strength: 44,000 psi
  • Elongation: 26%
  • Compliance: ANSI/AWS A5.9 ER410, ASME SFA 5.9 ER410
