Alloy C22® is a nickel chromium molybdenum alloy wire designed for joining Hastelloy® C22®, 625, 825 or combinations of these alloys, or other Ni-Cr-Mo alloys to themselves or to stainless steels. Washington Alloy C22® is equivalent to Hastelly® C22® and is also used extensively for overlays and cladding of lower alloy steels. Washington Alloy C22® weld deposits offer better overall resistance to weld metal corrosion than most other Ni-Cr-Mo alloys such as C276, C4 and 625. Washington Alloy C22® has outstanding resistance to pitting, crevice corrosion and stress-corrosion cracking. This alloy is used in chemical processing application involving ferric and cupric and inorganic, chlorine formic and acetic acids, acetic anhydride, sea water, and brine solutions.
-
Alloy / Product Title: C22 (ENICRMO-10)
-
Wire Diameter: 0.035 in
-
Length: 36 in
-
Weight: 10 LB
-
AWS Specification: A5.14 ERNiCrMo-10
-
Typical Tensile Strength: 115,000 psi
-
Typical Yield Strength: 77,000 psi
-
Typical Elongation: 47%
-
Carbon Content: 0.015% max
-
Manganese Content: 0.50% max
-
Iron Content: 2.0-6.0%
-
Phosphorus Content: 0.02% max
-
Sulphur Content: 0.010% max
-
Silicon Content: 0.08% max
-
Copper Content: 0.50% max
-
Molybdenum Content: 12.5-14.5%
-
Cobalt Content: 2.50% max
-
Nickel + Cobalt Balance: Balance
-
Chromium Content: 20.0-22.5%
-
Vanadium Content: 0.35% max
-
Tungsten Content: 2.5-3.5%
