ER625 is a nickel-chromium-molybdenum filler metal used for MIG, TIG, submerged arc and plasma arc welding of Inconel® alloys 601, 625 and 690 as well as Incoloy® alloys 800, 825 and 800HT to themselves or to each other. Washington Alloy 625 is excellent for joining these Inconel® and Incoloy® alloys to dissimilar metals such as carbon steel, low alloy steel, ferritic and austenitic stainless steels. This filler metal produces weld deposits with excel lent corrosion and oxidation resistance against phosphoric acids, organic acids and seawater. Good resistance against pitting and stress corrosion cracking in chloride containing environments. The weld deposits exhibit high strength and fatigue resistance over a broad range of temperatures ranging from cryogenic up to 1800°F. ER625 is most commonly used in the chemical processing industry, pollution control equipment, marine equipment, nuclear reactor components, pump shafts.
-
Size: 0.030 in.
-
Length: 36 in.
-
Alloy Type: ERNiCrMo-3
-
Material: Nickel-Chromium-Molybdenum
-
Weight: 10 lb
-
Temperature Range: Cryogenic to 1800 F
-
Tensile Strength: 110,000 psi
-
Yield Strength: 60,000 psi
-
Elongation: 30%
-
Chemical Composition - Carbon: 0.10% max
-
Chemical Composition - Manganese: 0.50% max
-
Chemical Composition - Iron: 5.00% max
-
Chemical Composition - Phosphorus: 0.020% max
-
Chemical Composition - Sulfur: 0.015% max
-
Chemical Composition - Silicon: 0.50% max
-
Chemical Composition - Copper: 0.50% max
-
Chemical Composition - Niobium + Tantalum: 3.15-4.15%
-
Chemical Composition - Cobalt: 0.12% max (if specified)
-
Chemical Composition - Chromium: 20.0-23.0%
-
Chemical Composition - Nickel + Cobalt: 58.0% min
-
Chemical Composition - Titanium: 0.40% max
-
Chemical Composition - Aluminum: 0.40% max
-
Chemical Composition - Molybdenum: 8.0-10.0%
-
Compatible Alloys: Inconel 601, 625, 690; Incoloy 800, 825, 800HT; Carbon steel; Low alloy steel; Ferritic and austenitic stainless steels
-
Corrosion Resistance: Phosphoric acids, organic acids, seawater
-
Resistance Types: Pitting, stress corrosion cracking
-
Specifications: ANSI/AWS A5.14 ERNiCrMo-3, ASME SFA 5.14 ERNiCrMo-3
Downloads
Safety Data SheetTech datasheets
