Washington Alloy, TCU DEOX 26, Filler Metal, 3/32 in; ERCu, 98% Copper, 25,000-30,000 psi

Washington Alloy DEOX Copper is a 98% copper filler metal used for MIG, TIG, and oxyacetylene welding of copper and copper-alloyed base metals. DEOX Copper contains small amounts of phosphorus and silicon which act as the deoxidizing agents to promote sound weld joints. Washington Alloy DEOX Copper is easy flowing and produces weld deposits that are porosity-free, electrically conductive and the color will match that of copper. The oxyacetylene gas flame must be neutral or slightly oxidizing. Tip size must be one to two sizes larger than the base plate. Preheating should be done only if the part is thick. A boric acid or borax flux is recommended

• Weight: 30 lb
• Wire Diameter: 3/32 in.
• Filler Metal Type: ERCu
• Alloy / Product Title: Deox Copper ERCu
• AWS Standard: AWS A5.27 Rcu
• Material: Copper 98%
• Phosphorus Content: 0.15%
• Silicon Content: 0.50%
• Manganese Content: 0.50%
• Tin Content: 1.00%
• Lead Content: 0.02%
• Aluminum Content: 0.01%
• Maximum Other Elements: 0.50%
• Tensile Strength: 25,000-30,000 psi
• Electrical Conductivity: 40% IACS annealed
• Melting Point: 1967 F
• Density: 0.31 lbs/in3
• Brinell Hardness: 50-60
• Elongation: 29%
