Washington Alloy, TC 70S-6 16, Welding Wire, ER70S-6; .045 in, 11 lb, 80,380 psi

ER70S-6 contains high levels of manganese and silicon for stronger deoxidizing power where stringent cleaning procedures are not possible. This wire has been designed to provide X-ray quality porosity-free welds and the highest tensile strength (as welded) of the plain carbon steel wires. The high silicon content increases the fluidity of the weld pool, creating a smoother bead appearance and resulting in minimal post-weld grinding. ER70S-6 is excellent where poor fit-ups or rusty and oily plates may be used

• Grade: ER70S-6
• Wire Diameter: .045 in
• Spool Weight: 11 lb
• Carbon Content: 0.074%
• Manganese Content: 1.522%
• Silicon Content: 0.953%
• Tensile Strength: 80,380 psi
• Yield Strength: 66,587 psi
• Elongation: 24.2% in 2 in
• Charpy V-notch Impact: 28 ft lbs at -20 F
• Copper Coating Content: 0.5% max
• AWS Specification: AWS A5.18 ER70S-6
