Miller Electric, 907847, Engine-Driven Welder, 11 gal Fuel Tank, 230 A Max DC Amperage, Vanguard Engine, 2400 RPM Idle Speed

Reliable multiprocess engine-driven welder primarily used for Stick welding and creating power. Cost-effective engine-driven welder designed for maintenance and repair operations, construction, field fabrication, farm/ranch and work trucks.

Features

• Full auxiliary power at any setting.
• Over 100 pounds lighter and 13 percent smaller than previous models.
• Easy arc starts and less spatter.
• Single knob adjustment for quick and precise setup.
• With its intuitive design, the daily maintenance of our engine-driven welder is fast and easy.
• Kohler or Vanguard.

Does Not Include

• Weld leads

• Amperage Range: 20 A - 230 A
• Voltage: 29.2 V (Stick), 25.5 V (MIG/FCAW)
• Power Source: Engine-driven
• Horsepower: 23 hp
• Engine Idle Speed: 2400 RPM
• Engine Weld Speed: 3600 RPM
• Fuel Type: Gasoline
• Fuel Tank Size: 11 Gallon
• Single-Phase Generator Peak Power: 11000 W
• Single-Phase Generator Continuous Power: 9500 W
• Welding Type: Stick
• Current Type: DC
• Max DC Welding Amperage: 230 A
• Min DC Welding Amperage: 20 A
• Weld Output: CC / CV
• Weldable Metals: Stainless Steel, Steel
• Rated Output: CC/DC Stick 230 A at 29.2 V, 100% duty cycle, CV/DC MIG/FCAW 230 A at 25.5 V, 100% duty cycle
• Length: 37.06 in.
• Width: 20.13 in.
• Height: 26.5 in.
• Weight: 376 lbs
• Sound Rating: 64 dB @ idle, 73 dB @ weld
• Engine Brand: Vanguard
• Country of Origin: United States
• Model: Bobcat 230 (Vanguard)
