Washington Alloy, TCU LFB/11, Brazing Rod, RBCuZn-C, 3/8 in, 36 in, Yellow Brass

Washington Alloy Low Fuming Bronze is a general-purpose oxyacetylene brazing rod used for steel, copper alloys, cast iron, nickel alloys, and stainless steel. A balanced chemical analysis of copper and zinc, as well as alloying elements of tin, iron, manganese, and silicon, produce weld deposits that are easily attained simply by applying a neutral or slightly oxidizing flame. The high silicon content of Washington Alloy Low Fuming Bronze keeps fumes to a minimum. Preheating is required for some applications and bronze brazing flux is required for the bare rods

• Alloy Type: RBCuZn-C
• Rod Diameter: 3/8 in.
• Rod Length: 36 in.
• Tensile Strength: 60,000-68,000 psi
• Hardness: 80-100 Brinell
• Solidus Temperature: 1590 F (866 C)
• Liquidus Temperature: 1630 F (888 C)
• Brazing Range Temperature: 1330-1550 F (721-843 C)
• Material Composition: Copper 56-60%, Zinc Balance, Tin 0.80-1.10%, Iron 0.25-1.20%, Manganese 0.01-0.50%, Silicon 0.04-0.15%
• Flux Requirement: Bronze brazing flux required for bare rods
• Preheating Requirement: Required for some applications
• Color: Yellow Brass
• Compliance: AWS A5.8/A5.8M, ASME SFA5.8
• Weight: 10 LB
