Harris Products Group, 40T518L, Silver Brazing Alloy, 0.08 lb, Cadmium-Free, Fluidity 6.5, Copper; Brass; Steel

Safety-Silv® 40T brazing filler metal is primarily designed for brazing copper, brass, and steel. The melting range allows it to be used where part clearance cannot be tightly controlled. The tin addition is included to reduce the melting temperature and allow a slightly lower silver content. The result is an alloy with good flow characteristics and the opportunity for cost reductions when compared to traditional 45% silver alloys.

Features

• Fluidity rating of 6.5
• Maintains good mechanical properties
• Complies with the EU Reach & RoHS directive
• Forms excellent fillets
• Cadmium-free brazing alloy
• Ideal for brazing copper, brass and steel
• Use where part clearance cannot be tightly controlled

• Weight: 0.08 lbs
• Silver Content: 39.0-41.0%
• Zinc Content: 26.0-30.0%
• Copper Content: 29.0-31.0%
• Tin Content: 1.5-2.5%
• Melting Range: 1220-1310 F (660-710 C)
• Density: 4.76 troy oz/cu.in.
• Electrical Conductivity: 18.00 % IACS
• Material: Cadmium-free silver brazing alloy
• Compliance: ANSI/AWS A5.8 Class BAg-28, ASME SFA5.8 Class BAg-28, ISO 17672 Ag 140, EU REACH, RoHS
