Harris Products Group, 40F3184, Brazing Alloy, Cadmium-Free; Flux-Coated; Medium Temperature; Ductile

Safety-Silv® 40FC flux-coated is a ductile, free-flowing alloy that offers economy, good penetration into tight connections and medium temperature. Silver to light yellow color like polished brass.

Features

• Often used for corrosion applications or high temperature service, so suitability for the brazing alloy should be evaluated for the intended condition
• Flux-coating eliminates the need for manual flux application
• Complies with EU RoHS directive
• Suitable for brazing assemblies with wider gaps
• Cadmium-free, silver brazing alloy
• Moderate temperature alloy with a medium plastic range
• Good ductility
• Good replacement for hazardous cadmium bearing filler metals
• Corrosion resistance is generally similar to the copper base metal, but phosphorus containing alloys, including Stay-Silv® 40, should not be used if the braze is exposed to sulfur or sulfur compounds in service

• Weight: 0.28 lbs
• Silver Content: 39.0-41.0%
• Zinc Content: 27.5-31.5%
• Copper Content: 29.5-31.5%
• Other Elements: 0.15% max
• Solidus Temperature: 1250 F (677 C)
• Liquidus Temperature: 1350 F (732 C)
• Density: 4.76 troy oz/cu. in.
• Electrical Conductivity: 20.3% IACS
• Flux Coating: Flux-coated rod
• Compliance: EU RoHS Directive
• Color: Silver to light yellow
• Temperature Range: Medium temperature
• Ductility: Good
• Cadmium Content: Cadmium-free
