Harris Products Group, 40350H, Brazing Alloy, Cadmium-Free, Medium Temperature, Good Ductility

Safety-Silv® 40 is a ductile, free-flowing alloy that offers economy, good penetration into tight connections and medium temperature. Silver to light yellow color like polished brass.

Features

• Fluidity rating of 8.0
• Moderate temperature alloy with a medium plastic range, making it suitable for brazing assemblies with wider gaps
• Good replacement for hazardous cadmium-bearing filler metals
• Cadmium-free, silver brazing alloy
• Often used for corrosion applications or high temperature service, so suitability for the brazing alloy should be evaluated for the intended condition
• Corrosion resistance is generally similar to copper base metal, but due to its zinc content it should not be used if the braze is exposed to concentrated corrosive liquid for long periods of time
• Complies with the EU Reach & RoHS directive
• Good ductility

• Weight: 0.07 lbs
• Silver Content: 39-41%
• Zinc Content: 27.5-31.5%
• Copper Content: 29.5-31.5%
• Other Elements: 0.15% max
• Solidus Temperature: 1250 F (677 C)
• Liquidus Temperature: 1350 F (732 C)
• Density: 4.76 troy oz/cu.in.
• Electrical Conductivity: 20.3% IACS
• Fluidity Rating: 8.0
• Compliance: EU Reach, RoHS
• Color: Silver to light yellow (polished brass appearance)
