Harris Products Group, 38T350, Brazing Alloy, Cadmium-Free, High Silver Content, 0.07 lb

Safety-Silv® 38T high silver, cadmium-free, brazing filler metal has good flow properties and excellent fillet forming qualities. Safety-Silv® 38T produces high strength, ductile joints. It is an economical brazing alloy for brazing ferrous and nonferrous metals often selected to replace higher silver content brazing alloys. Conforms to the EU Reach & RoHS directive.

Features

• Ideal replacement for higher silver content brazing alloys due to its tin content
• Economical and cadmium-free brazing alloy
• Used to braze ferrous and nonferrous metals
• Excellent fillet-forming characteristics
• Complies with the EU Reach & RoHS directive
• Yields very strong, ductile joints
• Fluidity rating of 7.0
• Good flow properties

• Weight: 0.07 lbs
• Silver Content: 37.0 - 39.0 %
• Copper Content: 31.0 - 33.0 %
• Zinc Content: 26.0 - 30.0 %
• Tin Content: 1.5 - 2.5 %
• Other Content: 0.15 %
• Solidus Temperature: 1220 F (649 C)
• Liquidus Temperature: 1330 F (721 C)
• Electrical Conductivity: 18.0 % IACS
• Electrical Resistivity: 9.50 cm
• Density: 4.77 Troy oz/cu in
• Specific Gravity: 8.89
• Material Type: Cadmium-free high silver brazing alloy
• Compliance: ANSI/AWS A5.8 Class BAg-34, ASME SFA 5.8, ISO 17672 Ag 138, REACH & RoHS Compliant
